IMO 16A DC Isolator – 2-Pole 1-String

IMO offers a range of DC isolators designed for use in Solar PV Installations. The IMO design features an advanced switching action where the handle triggers a spring to snap the contacts rapidly. The disconnection of the load circuits and the suppression of the arc produced by a constant DC load is normally extinguished within 3ms.

The handle can be padlocked into the off position, meaning that if work needs to be done to the inverter, the DC supply can be safely and securely isolated.

• Rated insulation voltage: 800V
• Rated current: 16A
• Number of DC poles: 2
• 5 year warranty
• NEMA 4X and IP66 rated
• Box Dimensions: 180mm x 98mm x 80mm
• Product ID: SI16-PEL64R-2
